Aptamer-target interaction descriptor
Aptamer-target interaction information
Interaction ID: 821
Aptamer sequence: ATCGTCTGCTCCGTCCAATAGCGTGCATTGGTTTACTGCATCCGTGAAACTGGGCTTTGGTGTGAGGTCGTGC
Target unique ID: CRM-CCL-185
| Aptamer ID | Aptamer descriptor | Target chemistry | Target name | Affinity | Binding Conditions/Buffer | PubMed ID |
|---|---|---|---|---|---|---|
| Apta_739 | TV03 | Cell | vaccinia virus–infected and–uninfected lung cancer A549 cells | 4.1 nM | Dulbecco PBS, 4.5g/L glucose, 5 mmol/L MgCl2, 0.1 g/L yeast tRNA, 100 mL/L FBS, and 1 g/L BSA | 19246617 |
Structure information of aptamer
| Aptamer Sequence: | ATCGTCTGCTCCGTCCAATAGCGTGCATTGGTTTACTGCATCCGTGAAACTGGGCTTTGGTGTGAGGTCGTGC |
| The optimal secondary structure in dot-bracket notation: | ..(((((((.(((((((...(((((((.........))))..))).....)))))...)).)).))).))... |
| The centroid secondary structure in dot-bracket notation: | ..((....((((..((((.(((.((((.........)))).............))))))).).)))..))... |
The MFE structure
The Centroid structure
The mountain plot representation
Aptamer information
| Type | Detail | Type | Detail |
|---|---|---|---|
| Aptamer ID | Apta_739 | Description | TV03 |
| Aptamer chemistry | DNA | Length | 73 nt |
| GC content | 53.4% | Molecular weight | 22,538.38 Da |
| Molarity of 1 μg/μl solution | 22,538.38 Da | Number of G-quadruplexes | No QGRS found |
| G-Score | N/A | Function | Target recognition |
| Sequence | ATCGTCTGCTCCGTCCAATAGCGTGCATTGGTTTACTGCATCCGTGAAACTGGGCTTTGGTGTGAGGTCGTGC | ||
| Applications | Detection of A549 cells | ||
Target information
| Type | Detail | Type | Detail |
|---|---|---|---|
| ATCC ID | CRM-CCL-185 | Cell name | vaccinia virus-infected and-uninfected lung cancer A549 cells |
| Category | Human cells | Organism | Homo sapiens, human |
| Product type | Certified reference material | Cell type | epithelial cell |
| Morphology | epithelial | Tissue | Lung |
| Disease | Carcinoma | Product format | Frozen |
| Antigen expression | N/A | Genes expressed | N/A |
| Cell description | N/A |
|
|
| Application(s) | Assay development | ||
Activity data
|
No relevant experimental diagram |
Interaction ID | 821 |
| Target type | Cell | |
| Target unique ID | CRM-CCL-185 | |
| Activity | 4.1 nM | |
| Binding Conditions/Buffer | Dulbecco PBS, 4.5g/L glucose, 5 mmol/L MgCl2, 0.1 g/L yeast tRNA, 100 mL/L FBS, and 1 g/L BSA |
|
| Assay | N/A |
|
| PubMed ID | 19246617 |
Similar aptamers
| Aptamer ID | Aptamer chemistry | Sequence | Similarity |
|---|---|---|---|
| Apta_737 | DNA | ATCGTCTGCTCCGTCCAATAGTGCATTGAAACTTCTGCATCCTCGTTTGGTGTGAGGTCGTGC | |
| Apta_740 | DNA | ATCGTCTGCTCCGTCCAATAAACCTGCATAATTTATAAGTCTAGACTGCTGCATTTGGTGTGAGGTCGTGC | |
| Apta_738 | DNA | ATCGTCTGCTCCGTCCAATACCTGCATATACACTTTGCATGTGGTTTGGTGTGAGGTCGTGC | |
| Apta_741 | DNA | ATCGTCTGCTCCGTCCAATAGCCTCACCCTGCATAATTTATAGACTACACTTAGGAATCGCTGCATTTGGTGTGAGGTCGTGC | |
| Apta_743 | DNA | ATCGTCTGCTCCGTCCAATATCCGAGCAAGAACTCATATTGCATTATTTATAGCTACGCGCTGCATTTGGTGTGAGGTCGTGC | |
| Apta_736 | DNA | ATCGTCTGCTCCGTCCAATATGATGACACCTGCATAATTTATAGTGAGTCTTGATTCACGCTGCATTTGGTGTGAGGTCGTGC | |
| Apta_742 | DNA | ATCGTCTGCTCCGTCCAATAGGACCGATAGGAACCACGGACTGCATGTTTCTGCATTTGACGTGGTTTGGTGTGAGGTCGTGC | |
| Apta_791 | DNA | ATCGTCTGCTCCGTCCAATATATCAAAGGCGAATTTTGTCAAGGTGTTAAACGATAGTCCCTACCTTTGGTGTGAGGTCGTGC | |
| Apta_1051 | DNA | ATCCGTCACACCTGCTCTATACACATTGTGTTTACTCCCAGTTTTTTAGACTTATGGTGTTGGCTCCCGTAT | |
| Apta_732 | DNA | AAGGAGCAGCGTGGAGGATAGCTGTCATCGGCTTATGTGCTTTCCAGGGTCCGTGCTGTCCGTTGTTAGGGTGTGTCGTCGTGGT | |
| Apta_621 | DNA | AAGCTTGCTTTATAGCCTGCAGCGATTCTTGATCGGAAAAGGCTGAGAGCTACGC | |
| Apta_657 | DNA | CCTGCACCTCGTCCAGCATGCACACCGATGGCGGTCCTGTTTTACGGTAGCTTATATGCAGGGGGTGTGCGTGGGGAGGTGCGGTTGC | |
| Apta_554 | DNA | TGTACCGTCTGAGCGATTCGTACCATTAGTGGGTGCTCCTTACCTGATGGTCATCTAGCCAGTCAGTGTTAAGGAGTGC | |
| Apta_555 | DNA | TGTACCGTCTGAGCGATTCGTACGGATTGGGTTTGCACTTTACCTGCGGTGCATCGCAGCCAGTCAGTGTTAAGGAGTGC | |
| Apta_511 | DNA | ATCCGTCACACCTGCTCTCAGGGGATCACATTCTTGACGGTGTGATACAGTGCCTGGTGTTGGCTCCCGTAT | |
| Apta_595 | DNA | AGCGAGGGCGGTGTCCAACAGCGGTTTTTTCACGAGGAGGTTGGCGGTGG | |
| Apta_721 | DNA | CTCTCGGGACGACCGCGGTAGTCTTAACCTAAAGCGGTGTCAGGTCGTCCC | |
| Apta_826 | DNA | ATCCGTCACACCTGCTCTGCACGGGCTCAGTTTGGCTTTGTATCCTAAGAGGGATGGTGTTGGCTCCCGTAT | |
| Apta_899 | DNA | ATCCGTCACACCTGCTCTCGAATAGAGTATTCGATACTGACTTTATTTACCGTCTGGTGTTGGCTCCCGTAT | |
| Apta_1231 | DNA | ACCACCGGCCCGAGATAGTCTAGACCACTATGTTGTTGTGCTTACTGCTGTGTGGTGTGG |
